Product Description

Features:

• Large High Scale RC Model
• Radio Controlled 2.4GHz 8 channel EDF jet (Aileron, Elevator, Rudder, Throttle, retracts with doors, bomb drops)
• Full mechanical retracts with full retract bay doors and bomb bay
• Blue LED Strobe for night flying and stealth bombing
• Turning front-wheel
• Rudder to help steer plane on ground on its scaled landing gear for easy take offs
• EPS material, High simulation; Unique model design, copy the most expensive plane in the world; Fine making in details.
• Hidden Electronically retractable landing gears; Totally 10 wheels loaded.
• Hidden Bomb cabin, dropping bombs function in flying.
• Stable invert flight; Great stability of nosing up and down; Excellent hedgehopping performance, could complete all kinds of actions.
• Twin 64mm EDF units. (Electric Ducted Fans)
• High speed (could be 120km/h).
• 2.4GHz spectrum remote transceiver available, with the functions of automatic identification and precise code pairing, strong anti-jamming, and allow more than 20 aircrafts to fly at the same field at same time.

Specification:

Product Name:	B2 Spirit
Length:	700mm
Wingspan:	1605mm
Wing Area:	48d㎡
Material:	EPS Foam
Flying Weight:	1550g
Thrust:	More than 1650g
EDF Diameter:	64mm
Radio:	8 Channel
Servo:	11x 9g high speed micro servos
Speed Controller:	2x 30A Brushless ESCs
Control System:	2.4GHz Multifunctional Transmitter and Receiver
Drive System:	2x 3500KV Brushless Outrunner Motors
Aircraft Battery:	Li-Po 14.8v/5200mAh (25C)



Product Info:

This Aircraft is NOT A TOY. It is not suitable for children under 14 years of age. Children under the age of 14 must not operate this product alone.  They must be accompanied by an experience adult at all times.



Flying Skill Level:

Advanced and experienced pilots recommended.

Build Level:

Moderate airplane assembly required. Internal wiring and electronics configuration is required. Please dry fit and test all electronics before gluing and securing any components.

Maintenance Level:

After every 5 flights and before and after storing airplane, please check all control surface horns and tighten the screws on surface horns if needed. Check the control pushrod clevis to insure no cracks are visible and no clevis has come loose. Check all control surfaces for solid contact between control surfaces, main wings and tail sections. Check for any loose screws anywhere screws are located. Check all wires connecting to the receiver for solid connection.

Please Note: If you have very little knowledge of Model Plane Assemble or have no Radio Control Flying experience, we would NOT recommend you to purchase this product to learn on.



Package Includes:

There is no clear industry standard definition for RTF, ARF, RXR, KIT, etc. Every manufacturer makes up their own definitions. The generally accepted definitions are: KIT means that you get all of the components of the plane, i.e.: fuselage, wings, tail, landing gear, even ducted fan, etc., pre-built but not pre-assembled; No electronic parts are included. RTF (Ready To Fly) means that you get the complete model, which includes all electronic parts—equipped model itself and RC Transmitter, Receiver, Flight Battery and 90 – 98% assembled. All “RTF” versions will have slight final assembly and setting up to do before flying. Required items: RC transmitter AA batteries and Li-po flight battery charger depending on the model aircraft purchased. RXR means that you get the RTF but no RC transmitter/Receiver. ARF means that you get the RTF but no RC transmitter/Receiver and no aircraft Battery.
